SK hynix announced today that it has developed the industry’s highest 238-layer NAND Flash product.
The company has recently shipped samples of the 238-layer 512Gb triple level cell (TLC)1 4D NAND product to customers with a plan to start mass production in the first half of 2023. “The latest achievement follows development of the 176-layer NAND product in December 2020,” the company stated. “It is notable that the latest 238-layer product is most layered and smallest in area at the same time.”
The company unveiled development of the latest product at the Flash Memory Summit 20222 in Santa Clara. “SK hynix secured global top-tier competitiveness in perspective of cost, performance and quality by introducing the 238-layer product based on its 4D NAND technologies,” said Jungdal Choi, Head of NAND Development at SK hynix in his keynote speech during the event. “We will continue innovations to find breakthroughs in technological challenges.”
Since development of the 96-layer NAND product in 2018, SK hynix has introduced a series of 4D products that outperform existing 3D products. The company has applied charge trap flash3 and peri under cell4 technologies to make chips with 4D structures. 4D products have a smaller cell area per unit compared with 3D, leading to higher production efficiency.
The product, while achieving highest layers of 238, is the smallest NAND in size, meaning its overall productivity has increased by 34% compared with the 176-layer NAND, as more chips with higher density per unit area can be produced from each wafer.
The data-transfer speed of the 238-layer product is 2.4Gb per second, a 50% increase from the previous generation. The volume of the energy consumed for data reading has decreased by 21%, an achievement that also meets the company’s ESG commitment.
The 238-layer products will be first adopted for client SSDs which are used as PC storage devices, before being provided for smartphones and high-capacity SSDs for servers later. The company will also introduce 238-layer products in 1 Terabit (Tb) next year, with density doubled compared to the current 512Gb product.
All registered trademarks and other trademarks belong to their respective owners. For more details, please visit SK Hynix official site.
